SawStop Table Saws SawStop 5HP, 3PH, 230V Industrial Cabinet Saw 36" T-Glide Fence ICS53230-36 ICS53230-36
$5,822.00
Factory Direct Estimated Shipping in 1-4 Days -Direct from Factory
OPT SKU
KIT-SAWICS53230-36
FREIGHT SHIPPING
Due to the size/weight of this product, freight shipping is required.
Due to the size/weight of this product, freight shipping is required.
$425 FLAT RATE SHIPPING
Flat rate shipping is required for this product.
Flat rate shipping is required for this product.
SawStop - Summer Cast Iron E-REBATE
q226sawtsareb01
click to copy
Similar Products
SawStop Table Saws SawStop 3HP Professional Cabinet Saw 30" Premium Fence PCS31230-PFA30 PCS31230-PFA30 $3,551.00
KIT-SAWPCS31230-PFA30
SawStop Table Saws SawStop 1.75HP Contractor Saw 36" T-Glide Fence CNS175-TGP236 CNS175-TGP236 $2,329.00
KIT-SAWCNS175-TGP236
SawStop Table Saws SawStop 3HP Professional Cabinet Saw 36" T-Glide Fence PCS31230-TGP236 PCS31230-TGP236 $3,881.00
KIT-SAWPCS31230-TGP236
SawStop Table Saws SawStop 1.75HP Contractor Saw 30" Professional Fence CNS175-PFA30 CNS175-PFA30 $1,999.00
KIT-SAWCNS175-PFA30
SawStop Table Saws SawStop 5HP, 1PH, 230V Industrial Cabinet Saw 36" T-Glide Fence ICS51230-36 ICS51230-36 $5,822.00
KIT-SAWICS51230-36
SawStop Table Saws 1.75HP Professional Cabinet Saw 52" T-Glide Fence PCS175-TGP252 $3,461.00
KIT-SAWPCS175-TGP252
SawStop Table Saws 1.75HP Contractor Saw 52" T-Glide Fence CNS175-TGP252 $2,435.00
KIT-SAWCNS175-TGP252
SawStop Table Saws SawStop 1.75HP Professional Cabinet Saw 36" T-Glide Fence PCS175-TGP236 PCS175-TGP236 $3,355.00
KIT-SAWPCS175-TGP236
SawStop Table Saws SawStop 3HP Professional Cabinet Saw 52" T-Glide Fence PCS31230-TGP252 PCS31230-TGP252 $3,987.00
KIT-SAWPCS31230-TGP252
- (2) Cast Iron Extension Wings
- (1) Miter Gauge
- (1) Dust Collection Blade Guard
- (1) Riving Knife
- (2) Blade Wrenches
- (1) Push Stick
- (1) 10” Blade
- (1) Standard Lockdown Insert
- (1) Standard Brake Cartridge
- (1) Owner’s Manual
- (2) Hardware Packs
- (1) 3mm Hex Key
- (1) 5mm Hex Key
- (1) 8mm Hex Key
- (1) Blade Spacing Adjustment Gauge
- 36" Industrial T-Glide Fence System provides smooth operation, precision measurement and sure lockdown without deflection.
- Durable craftmanship and thoughtful details combine for consistent, reliable performance in the most demanding industrial environments.
- SawStop Safety System stops on contact with skin.
- Horsepower: 5HP
- Dimension: 69 1/4" w, 36 1/2" d, 34" h
| 36" Rip Capacity | 36" T-Glide Fence Assembly |
|---|---|
| Motor Option(s) (60Hz TEFC) | 3, 5, 7.5 HP available |
| Overall saw dimensions 36 in | 69 1/4" W x 36 1/2" D x 34" H |
| Motor configuration 3 | 5 HP, 3 phase, 230v, 12 A, 60Hz, TEFC |
| Saw body footprint | 20" W x 25" D (Cabinet) |
| Cast iron table | 24" W x 30" D |
| Cast iron table (w/ extension wings) | 44" W x 30" D |
| Extension wings | 10" W x 30" D each |
| Extension table 36 in | 24" W x 30" D |
| Shipping weights - w/ 36 in fence systems | 755 lbs (4 boxes) |
| Shipping dimensions (saw body only) | 40" W x 40" D x 40" H |
| Shipping weight (approx.) | 640 lbs (table saw only) |
| Assembled weights - w/ 36 in fence systems | 635 lbs. (approx weight, actual weight varies by motor size) |
| Weights - table saw only | 530 lbs. (approx weight, actual weight varies by motor size) |
| Blade | 40-tooth Titanium, 5/8" arbor |
| Blade diameter | 10" |
| Blade tilt | Left |
| Blade kerf | 0.118" (3mm) |
| Blade plate thickness | 0.078" (2mm) |
| Max. depth of cut, blade at 0º | 3 1/8″ |
| OPT SKU | KIT-SAWICS53230-36 |
|---|---|
| MPN | ICS53230-36 |
| UPC/GTIN | 857555005123 |
| Product Type | Table Saws |
| Google Category | Hardware > Tools > Saws > Table Saws |
| Diameter | 10" |
| Power Method | Corded/Electric |
| Package | Bundle |
| Voltage | 220V/240V |
| Shipping Weight | 810.00 |
