RIDGID 975 Combo Roll Groover 25638

Ridgid

975 Combo Roll Groover

The Model 975 Combo Roll Groover is two tools in one. Like other RIDGID roll groovers; the 975 mounts on the RIDGID 300 Power Drive for machine-powered roll grooving jobs. It also designed to manually roll groove in-place pipe.

FEATURES:

• Auto Tracking & Depth Setting Gauge Means Easier Use - The 975 Combo Groover includes new; patented auto tracking technology for significantly easier grooving. Whether you're doing machine-powered or manual grooving; the AutoTracking gauge keeps the pipe automatically engaged to the groover throughout the grooving process. The 975 also includes a permanently depth setting gauge for quicker; repeatable set-up.
• Less Hand Force Required - When manually roll grooving; the 975's 55% higher gear reduction means less hand force required versus competitive manual roll groovers. This is especially helpful for over-head roll grooving.
• Durability And Portability - A tough; ductile iron construction means the 975 can absorb jobsite abuse and provide accurate grooves time after time. A cast-in handle makes the 975 easily portable to and from the jobsite.

SPECIFICATIONS:

Capacity	1 6 Schedule 10 and Schedule 40 steel; aluminum; and PVC pipe/ 1 1/4 6" Schedule 10; 1 1/4" 2" Schedule 40 stainless steel pipe; 11/2" 3" Schedule 80 PVC pipe/ With roll change; 2" 8" copper tube (Type K; L; M; and DWV)
Depth Adjustment	Adjusting screw and integral; index depth gauge
Actuation	Feed screw with 1/2" ratchet wrench (included); or any 15/16" hex wrench
Power Drive Mounting	RIDGID 300 Power Drive 38/57 RPM (reverse direction only)
