Fein 18V Mag Drill 1-3/8" Cordless Slugger Magnetic Base (8.0Ah) KIT AmpShare 71700563090

Name: Fein 18V Mag Drill 1-3/8" Cordless Slugger Magnetic Base (8.0Ah) KIT AmpShare 71700563090
Brand: Fein
SKU: FEIN-71700563090

$2,499.95

Factory Direct

Estimated Ship Date: 09/11/2026 - 09/18/2026

OPT SKU

FEIN-71700563090

FREE SHIPPING @ 199+
Standard Ground (Lower 48 States)

What's Included

1 cordless magnetic core drill
1 centering pin dia. 1/4 x 3-9/16 [6.35 x 90] in[mm]
1 drift
1 coolant pump
1 centering pin dia. 1/4 x 3-1/4 [6.35 x 82] in[mm]
2 CORE 18 V / 8.0 Ah Li-Ion batteries
1 safety strap & tool case
1 centering pin dia. 1/4 x 4 [6.35 x 100] in[mm]
1 GAL18 V-160 AS rapid charger
1 chip hook & guard

Additional Details

The extremely durable cordless mag drill features a FEIN PowerDrive, designed for up to 60,000 holes over a 300-hour usage period. Lightweight and compact, it boasts 25% higher work progress and longer battery life compared to competitors. With an 18 V 8 Ah AMPShare ProCORE battery, it can achieve up to 31 holes per charge. Weighing only 26.9 lbs, it includes forward/reverse, electronic speed control, and a 10-1/4" stroke range for versatile applications. Operator controls are intuitively placed for visibility, and a magnetic holding force indicator ensures safe positioning. A tilt sensor safety shutoff enhances workplace safety. It features an MK2 tool mount, narrow permanent magnet with pre-magnetization, "Memory function" speed storage, and COOLPACK 2.0 technology for extended battery life. Advanced cell technology and intelligent battery management provide 87% more power than conventional batteries, with ECP protecting against overloading, overheating, and deep discharge.

Features

Extremely durable cordless mag drill with a FEIN PowerDrive designed for up to 60,000 holes during a 300 h usage period.
Small and lightweight machine with up to 25% higher work progress with one-of-a-kind productivity and longer storage battery life as compared to competitors. With an 18 V 8 Ah AMPShare ProCORE storage battery, up to 31 holes per battery charge are possible (Carbide cutter, 11/16" dia., mild steel 1/2").
The lightest cordless mag drill in the world at only 26.9 lbs. This drill features forward/reverse, electronic speed control, and 10-1/4" stroke range for maximum flexibility in all applications (drilling, tapping, twist drilling, reaming and countersinking).
Intuitive operator controls located on the top of the drill motor for maximum visibility.
A Convenient magnetic holding force indicator supports the safe positioning of the tool.
Workplace Safety: Tilt sensor safety shutoff will shut down the drill in the event it should move or break free from the workpiece.
MK2 tool mount for direct use of industrial tools.
Secure position thanks to extra narrow permanent magnet with pre-magnetization for convenient and simple alignment.
"Memory function" speed storage.
COOLPACK 2.0 technology ensures a 135% longer battery service life, enabling longer operation time.

Manufacturer Specifications

Battery voltage	18 V
Battery compatibility	Li-ion / CORE 18 V Li-ions
Battery interface	18 V AMPShare
Motor	Brushless
Full load speed	130 - 520
Tool mount	MT 2
Carbide cutter max. dia.	1-3/8 [35] in[mm]
HSS cutter max. dia.	1-3/8 [35] in[mm]
Cutter max. drilling depth	2 [50] (3 [75] )* in[mm]
Twist drill max. dia.	3/4 [18] in[mm]

Specifications

More Information
OPT SKU	FEIN-71700563090
MPN	71700563090
UPC/GTIN	4014586900407
Product Type	Mag Drills
Google Category	Hardware > Tools > Drills > Handheld Power Drills
Product Line	AmpShare
Power Method	Cordless
Package	Kit/Set
Voltage	18V
Shipping Weight	5.00
